Logic Analyzer 16Mhz 24Mhz Sampling 8 Channels Analyzer Development Board Module Type-C Interface MCU ARM FPGA Debugging Tool

Logic Analyzer 16Mhz 24Mhz Sampling 8 Channels Analyzer Development Board Module Type-C Interface MCU ARM FPGA Debugging Tool

Features:

1. Made of high-quality materials, durable and practical.

2. Exquisite and compact appearance, rich functions

3. Supports up to 24Mhz sampling rate and supports more than 100 protocol analysis

4. Can greatly improve development and debugging efficiency in scenarios such as problem location, complex systems with multiple components, timing analysis, performance analysis, etc.

5. Supports use on Windows/Linux/Mac platforms

Description:

This logic analyzer samples The maximum sampling rate supports 16-24MHz, and the maximum sampling rate is about 3MHz (the sampling rate needs to be at least 5 times that of the original signal, and 10 times the sampling rate is generally recommended to better restore the original signal). The maximum sampling rate is 24MHz, but not all PCs can achieve it. After actual testing, Linux can sample at 24MHz, and most Windows (win7/win10) can sample at 16MHz. The maximum sampling rate is related to the operating system/USB controller/USB bus status/USB driver.

Specifications:

Software environment: PuIseView

Sampling channels: 8 channels

Sampling frequency: up to 24Mhz

Logic level: low level is [-0.5v, 0.8v], high level [2v, 5.25v]

Package Included:

Mini logic analyzer*1
